REDUCED GLARE | VASARI PRO SERIES
A series of premium recessed downlights available in various sizes, shapes, and finishing. Paired with ELR’s highly configurable LED modules, the Vasari downlight series offers a high degree of flexibility, aesthetics and functionally for the most discerning of applications.
Module Colour Temperature Variation
HE
ProART
ProART98
ComfySHIFT
Warm Dim
tuneWHITE
flexiK
RGBW
RGBABeam Angle
8°
10°
12°
15°
20°
25°
35°
40°
60°Fixture Features
IP54 / IP65
Ceilling SafeDriver Dimming Variation
ND
PH
AN
DA
DT8
DMX
CSBVasari 2S Pro
Round Trim
Size: 60mm
Luminous Flux: 135 lm – 810 lm
LED Power: 7.6W – 12.2W
Colour Temperature: Single CCT, WD, TW, FK, CS
Ingress Protection: IP40, IP54 (room side), IP65 (room side)
Round Trimless
Size: 60mm
Luminous Flux: 135 lm – 810 lm
LED Power: 7.6W – 12.2W
Colour Temperature: Single CCT, WD, TW, FK, CS
Ingress Protection: IP40, IP54 (room side), IP65 (room side)
Round Trim
Size: 60mm
Luminous Flux: 135 lm – 810 lm
LED Power: 7.6W – 12.2W
Colour Temperature: Single CCT, WD, TW, FK, CS
Ingress Protection: IP40, IP54 (room side), IP65 (room side)
Round Trimless
Size: 60mm
Luminous Flux: 135 lm – 810 lm
LED Power: 7.6W – 12.2W
Colour Temperature: Single CCT, WD, TW, FK, CS
Ingress Protection: IP40, IP54 (room side), IP65 (room side)
WD = Warm Dim, TW = tuneWHITE, CS = ComfySHIFT, FK = flexiK, Single CCT = 2700K / 3000K / 3500K / 4000K / 5000K
Vasari 2G Pro
Round Trim
Size: 75mm
Luminous Flux: 135 lm – 810 lm
LED Power: 7.6W – 12.2W
Colour Temperature: Single CCT, WD, TW, FK, CS
Ingress Protection: IP40, IP54 (room side), IP65 (room side)
Round Trimless
Size: 75mm
Luminous Flux: 135 lm – 810 lm
LED Power: 7.6W – 12.2W
Colour Temperature: Single CCT, WD, TW, FK, CS
Ingress Protection: IP40, IP54 (room side), IP65 (room side)
Round Trim
Size: 75mm
Luminous Flux: 135 lm – 810 lm
LED Power: 7.6W – 12.2W
Colour Temperature: Single CCT, WD, TW, FK, CS
Ingress Protection: IP40, IP54 (room side), IP65 (room side)
Round Trimless
Size: 75mm
Luminous Flux: 135 lm – 810 lm
LED Power: 7.6W – 12.2W
Colour Temperature: Single CCT, WD, TW, FK, CS
Ingress Protection: IP40, IP54 (room side), IP65 (room side)
WD = Warm Dim, TW = tuneWHITE, CS = ComfySHIFT, FK = flexiK, Single CCT = 2700K / 3000K / 3500K / 4000K / 5000K
Vasari 3 Pro
Round Trim
Size: 84mm
Luminous Flux: 231 lm – 2162 lm
LED Power: 4.5W – 17W
Colour Temperature: Single CCT, WD, TW, FK, CS
Ingress Protection: IP40, IP54 (room side), IP65 (room side)
Round Trimless
Size: 82mm
Luminous Flux: 231 lm – 2162 lm
LED Power: 4.5W – 17W
Colour Temperature: Single CCT, WD, TW, FK, CS
Ingress Protection: IP40, IP54 (room side), IP65 (room side)
Round Trim
Size: 84mm
Luminous Flux: 231 lm – 2162 lm
LED Power: 4.5W – 17W
Colour Temperature: Single CCT, WD, TW, FK, CS
Ingress Protection: IP40, IP54 (room side), IP65 (room side)
Round Trimless
Size: 82mm
Luminous Flux: 231 lm – 2162 lm
LED Power: 4.5W – 17W
Colour Temperature: Single CCT, WD, TW, FK, CS
Ingress Protection: IP40, IP54 (room side), IP65 (room side)
WD = Warm Dim, TW = tuneWHITE, CS = ComfySHIFT, FK = flexiK, Single CCT = 2700K / 3000K / 3500K / 4000K / 5000K
Vasari 4 Pro
Round Trim
Size: 100mm
Luminous Flux: 974 lm – 3206 lm
LED Power: 12W – 23W
Colour Temperature: Single CCT, WD, TW, FK, CS
Ingress Protection: IP40, IP54 (room side), IP65 (room side)
Round Trimless
Size: 98mm
Luminous Flux: 974 lm – 3206 lm
LED Power: 12W – 23W
Colour Temperature: Single CCT, WD, TW, FK, CS
Ingress Protection: IP40, IP54 (room side), IP65 (room side)
Round Trim
Size: 100mm
Luminous Flux: 974 lm – 3206 lm
LED Power: 12W – 23W
Colour Temperature: Single CCT, WD, TW, FK, CS
Ingress Protection: IP40, IP54 (room side), IP65 (room side)
Round Trimless
Size: 98mm
Luminous Flux: 974 lm – 3206 lm
LED Power: 12W – 23W
Colour Temperature: Single CCT, WD, TW, FK, CS
Ingress Protection: IP40, IP54 (room side), IP65 (room side)
WD = Warm Dim, TW = tuneWHITE, CS = ComfySHIFT, FK = flexiK, Single CCT = 2700K / 3000K / 3500K / 4000K / 5000K
